Attenuation of pedestrianinduced vibrations in girder footbridges using tunedmass dampers
Advances in Bridge Engineering volume 1, Article number: 14 (2020)
Abstract
This article presents a numerical assessment of pedestrianinduced vibrations for a wide range of girder footbridges before and after the installation of tunedmass dampers (TMD). Realistic pedestrian loads are defined using a stochastic model that represents the key characteristics of pedestrians and their intra and intersubject variability with the aim of ensuring an accurate estimation of the dynamic response. A comprehensive set of numerical analyses have been performed considering different cross sections, structural materials, span lengths (up to 100 m), and pedestrian flows. The optimal TMD characteristics, number and location, required to reduce the accelerations, down to a level that fulfils serviceability criteria, are identified. Design recommendations for girder footbridges implementing damping devices at the design stage are also included.
Introduction
A key challenge for the bridge engineering community is addressing the design of increasingly slender footbridges, some of which also have relatively long spans. The main uncertainties are linked to the vibration problems that can arise in footbridges due to pedestrian traffic. If any of the footbridge natural frequencies lies near the strep frequencies of the pedestrians, resonant effects leading to large response may occur, and cause discomfort to users. In many cases, supplemental damping devices are required to mitigate humaninduced vibrations in footbridges. However, these devices are frequently chosen after the structure has been built to mitigate against unintended levels of vibration. There are also situations when they are included at the design stage, but are often designed in an overlay conservative manner.
In recent years, various studies have focused on developing methods to mitigate humaninduced vibration in pedestrian bridges, with most of the emphasis being given to vibration in the vertical direction (Fujino et al. 1993; Nakamura 2004; Dallard et al. 2001). However, excessive lateral vibrations registered at the Toda Park bridge (Tbridge) in Japan (Fujino et al. 1993; Nakamura 2004), the London Millennium Bridge (Dallard et al. 2001), and The Pont de Solferino (also known as Passerelle LéopoldSédarSenghor), in Paris (Danbon and Grillaud 2005) resulted in more intense research attention on the analysis of lateral vibrations. The London Millennium Bridge and the Passerelle LéopoldSédarSenghor were closed after their inaugurations in 1999 and 2000 respectively to implement damping devices to reduce unexpected severe lateral vibrations. Due to these highprofile cases, the dynamic response in the lateral direction is nowadays also considered during the design of footbridges (Charles et al. 2006; Butz et al. 2007). For lateral vibrations, research has focussed on the “lockin” effect, which is also referred to as synchronous lateral excitation. This effect is caused when pedestrians synchronize their step frequencies with the frequency associated with the lateral vibration of the structure. Many studies to date have proposed deterministic models for simulating humaninduced vibrations in the vertical and lateral directions through a periodic force using Fourier series. Nevertheless, the forces induced by each pedestrian are different in each successive step, and the real loading will depend on different parameters, such as: the physical and anthropometric properties of each pedestrian (weight, height, age, gender), parameters describing the pedestrian walking (speed, and step frequency), the acceleration registered in the bridge at the location where the pedestrian steps (pedestrianbridge interaction), the pedestrian density, and the route followed by pedestrians as a consequence of the pedestrianpedestrian interactions within the flow. These have been considered herein through the stochastic load model proposed by RamosMoreno et al. (2019). By bounding the vertical and lateral accelerations within the comfort limits (Charles et al. 2006; BSI 2003; ISO 2005), vibrational serviceability problems are avoided. After performing dynamic analyses under pedestrian loads, when excessive accelerations and displacements are obtained, supplemental damping devices may be considered as a solution to control the dynamic response. In recent years, experimental studies based upon field analysis, as well as numerical studies employing finite element methods, have provided useful information about how designers can reduce humaninduced vibration in footbridges using damping devices such as tuned mass dampers (TMD), tuned liquid dampers (TLD) and also viscoelastic dampers (Charles et al. 2006). These supplemental devices are being more frequently incorporated into footbridges after construction has finished, as a way to reduce unexpected humaninduced vibrations  such as the threespan steel box girder footbridge over the River Wharfe at Wetherby in Yorkshire, England (Jones and Pretlove 1981), and the Pedro e Inés footbridge in Coimbra, Portugal (Caetano et al. 2010).
Many of the studies related to the control of humaninduced vibrations in footbridges have been done using supplemental damping devices in existing structures. These studies have been conducted by the analysis of forces induced by a certain number of walking, running or jogging pedestrians (Caetano et al. 2010; Caetano and Cunha 2014). In some cases, when the damping system is introduced during service, the available space to deploy the damping devices is limited leading to the design of special dampers (Meinhardt 2008). Tuned mass dampers have often been selected over alternative damping devices due to their low cost, and high reliability and efficiency in the mitigation of vibration under pedestrian loads. Over the last few years, research has been developed to optimize the placement and properties of multiple tuned mass dampers through deterministic approaches in order to reduce humaninduced vibration in pedestrian bridges (Krenk et al. 2005; Daniel et al. 2011). However, a rigorous methodology that focusses on the optimal location and the properties of the tuned mass dampers in footbridges, considering the nonlinearities induced by the pedestrian loads in the vertical and lateral directions (RamosMoreno et al. 2019), is not yet available. Therefore, the novelties of this research work are: (1) the development of a comprehensive study focused on beam footbridges (considering different materials, cross sections, and a wide range of span lengths) using a very sophisticated load and numerical model that, through stochastic analyses considering the intra and intervariability of the pedestrian action, the interaction between pedestrians within the crowd flow, the pedestrianstructure interaction, as well as the nonlinearities of the pedestrian actions both in vertical and lateral direction; (2) the set of original conclusions and design recommendations obtained from this work. The purpose of the present study is to fill this gap in the literature and to define how and where to position these devices during the design stage in order to reduce the dynamic response in service, comply with serviceability design criteria, and further demonstrate the benefits of TMDs.
To investigate the efficiency of TMDs, the dynamic response is evaluated through numerical analyses, with and without these devices. Building upon previous research, this work aims to facilitate the design of a range of footbridges through a stochastic model of pedestrian traffic and an efficient damper arrangement. The structure of the paper is as follows. Firstly, the problem formulation is presented in which the girder footbridge characteristics, pedestrian load representation, serviceability criteria, and damping devices are described. Secondly, the design methodology outlining how TMDs should be implemented is described. The parametric analyses conducted and presented herein consider the criteria for selecting the properties of the TMDs, span lengths, cross sections types, structural materials, and the types of pedestrian flows as variables. The procedure identifying the locations where the TMDs should be deployed is illustrated, and the effects of implementing different numbers of dampers and their effectiveness are analysed. In addition, a cost comparison between either changing structural parameters (without implementing supplemental damping devices) or employing TMDs as a strategy to mitigate the humaninduced vibrations down to admissible levels is provided. Finally, design recommendations are provided.
Problem formulation
Footbridge characteristics
A set of singlespan girder footbridges (Table 1), using a comprehensive set of structural materials (reinforced concrete, prestressed concrete, steel, steel and concrete composite sections, timber, aluminium and glassfibre reinforced polymersGFRP), is analysed herein. Table 1 includes the most conventional span lengths. Nevertheless, some of the analyses of this paper cover a wider range of spans for purpose of providing more comprehensive description of the response. We investigate the dynamic response of each footbridge under pedestrian loading, with and without implementing TMDs. The deck widths vary between 2 to 5 m. The material properties of the girder footbridges were selected according to the standards shown in Table 2. These footbridges, without supplemental damping devices, were studied by RamosMoreno et al. (2019), and it was shown that the serviceability limit state (SLS) of vibration is not satisfied for certain spans for each section type, as the structural frequencies match the pedestrian frequency. It was also reported that the SLS of vibration cannot be satisfied for sections types 9 and 10 by changing the geometry and sectional dimensions. The objective of this work is to show whether the implementation of TMDs could lead to the verification of the vibration criteria for all these cases.
Pedestrian load representation
The evaluation of the dynamic response of the girder footbridges is performed considering the stochastic model proposed by RamosMoreno et al. (2014, 2017, 2019, 2020) which includes the simulation of pedestrians walking over the deck and considers the different anthropometric characteristics of each pedestrian, the vertical and lateral forces that each step transmits to the structure, the intra and intersubject variability, and the pedestrianpedestrian interactions within the pedestrian flow. Figure 1 summarises the pedestrian model that was adopted in this study. This approach is based on modelling the vertical loads using the model by Butz et al. (2007) and the lateral loads using the inverted pendulum model proposed by Bocian et al. (2012), and Carroll et al. (2013). The social force model proposed by Helbing and Molnar (1995) is considered to simulate the pedestrian flow and crowd interaction. Several experimental tests have been recorded to develop and validate the different pedestrian loads models used herein, such as Charles et al. (2006), Carroll et al. (2013), Townsend (1985), Pizzimenti and Ricciardelli (2005), Živanović et al. (2007), and Ingólfsson et al. (2011). The pedestrian model of RamosMoreno et al. (2019) is capable of describing in a realistic way the loads transmitted by each pedestrian.
Pedestrian intervariability
Each pedestrian is sampled from data representing the UK population. The velocity (v_{p}) of each pedestrian is derived from three different factors (Eq. 1): the free velocity (v_{f}), based on the anthropometric characteristics (i.e., the age (a_{p}) and the height (h_{pd}), Eq. 2), a factor (ϕ_{j}) related to the aim of the journey (1.11 for commuting activities and 0.86 for leisure activities), and a factor (ϕ_{d}) to consider the influence of the pedestrian density (d in units of pedestrians per metre square) (Eq. 3). Groups of pedestrians are considered by assigning similar desired speeds to the pedestrians in the group (governed by the slowest in the group) and forcing them to remain within a particular distance of each other.
The pedestrian frequency (Eq. 4) is related to the pedestrian velocity, while the free step width (w_{st}) (Eq. 5) is also related to the pedestrian height.
Vertical loads
The simulation of vertical loads is based upon the observed temporal distribution of foot loads from empirical studies. Butz et al. (2007) defines the vertical force transmitted through each foot onto the ground through nine key properties defined in Fig. 2, leading to a ninthdegree polynomial (Eq. 6). The coefficients, p_{i}, of the polynomial can be derived, for any step frequency in Table 3, by solving a system of ten equations (five known points and their derivatives) with ten unknowns. This function describes a doubleheap curve for the frequency interval in Table 3, where t_{end} is the total footground contact time, m_{A} (Eq. 7) is the gradient at the beginning of the step, F_{max,1}/G is the maximum value of the normalized force for the step, F_{min}/G is the value at the transition from heel strike to forefoot loading, F_{max,2}/G is the value of the normalized force when the pedestrian’s foot pushes off the ground, and m_{B} (Eq. 8) is the gradient of the force when the foot is pushing off the ground. The parameters for intermediate frequency values can be obtained through linear interpolation.
As the vertical forces depend on the pedestrian frequency (Table 3) and this in turn on the pedestrian speed (Eq. 1), which is in turn related to the pedestrian density (Eq. 2 and 4), the traffic action, and therefore the structural response, varies nonlinearly with the pedestrian density.
Lateral loads
While the lateral ground reaction forces imparted by pedestrians are relatively small compared to the corresponding vertical loads, pedestrians may synchronize their step frequency with the lateral frequency of the bridge, when the lateral accelerations are above certain thresholds, inducing resonant effects. In order to consider the variability of lateral pedestrianinduced loads, which are related to the pedestrian stability while walking, researchers have considered lateral load models described by an inverted pendulum (IP). This model represents a pedestrian’s movement in time as a function of the position of the pedestrian centre of mass (CoM) (RamosMoreno et al. 2019; Bocian et al. 2012; Ingólfsson et al. 2011) (Fig. 3).
This IP model shows that the CoM movement has a relationship between the gait, the step width, the anthropometric characteristics of the person and the lateral acceleration of the structure in the vicinity of the pedestrian (Macdonald, 2009). Equations (9, 10 and 11) are used to define the resulting lateral force (F_{l}) introduced by the pedestrian on the structure in that particular step.
where: L_{eq} represents the distance from the centre of pressure to the CoM, m_{p} is the mass of the pedestrian, g is gravitational acceleration, u_{s} is the lateral displacement of the structure (therefore \( {\ddot{u}}_s \) is the lateral acceleration of the structure in global axes), w_{s} is half of the step width in local axis, y is the position of the CoM in local axis of the deck (therefore \( \ddot{y} \) is the acceleration of the CoM in the local axis), g_{L} and g_{N} are the parallel and normal components of the gravitational acceleration. Ω_{p} is defined as the natural frequency of the lateral movements of the CoM and is given by \( {\Omega}_p=\sqrt{\frac{g}{L_{eq}}} \).
As the lateral forces introduced by each pedestrian depend on the acceleration of the deck at the location where the pedestrian steps, and these are induced in turn by the lateral forces applied, the traffic action and therefore the response is nonlinearly related to the pedestrian density.
Crowd modelling
A social force model for humans was used to consider the human interactions while the pedestrians are crossing the bridge. This model has been applied in transportation, and evacuation studies and also in footbridges (e.g., Carroll et al. 2013; Helbing and Molnar 1995; JimenezAlonso et al. 2016). In this social force model, the resultant force (F_{T}) (Eq. 12), which is needed to describe the pedestrian trajectory at each location, is the sum of the driving force (F_{D}), and the forces induced by the interaction with other pedestrians (F_{P}), and by the physical interaction with geometrical boundaries (F_{B}).
The driving force or motive force is the motivation that the person has to reach the destination (Eq. 13). This is computed from the pedestrian mass (m_{p}), the desired velocity (v_{d}), the actual velocity (v_{p}) and the relaxation time (t_{r} = 0.50s).
The interaction among pedestrians is based on the sum of social and physiological forces. The social forces correspond to the pedestrians’ willingness to maintain some distance from other pedestrians while crossing the bridge. The physiological forces avoid physical damage from any possible physical contact with other pedestrians, and prevent pedestrians overlapping when the distance between individuals is minimal (as forces relate to pedestrian centroids). The interaction forces induced by boundaries ensures that the pedestrians will keep a certain distance from any obstacle or geometrical constraint such as remaining within the footpath. These three force components in Eq. (12) are clearly defined by JimenezAlonso et al. (2016).
Pedestrian intravariability
Each pedestrian crosses the footbridge, starting at an arrival time (following to a Poisson process) and at a lateral position across the deck width (according to a uniform distribution). With these considerations, an initial lateral position and velocity is defined for each pedestrian. A uniform distribution over [0.0, 0.75], where 0.75 m represents the maximum considered value of step length, is used to represent the initial step position along the deck.
The subject variability (intravariability) in the step frequency is represented through MarkovChain Monte Carlo (MCMC) simulation that ensures that individuals vary their step frequency according to some overall distribution, with successive frequencies being autocorrelated depending on the value of its magnitude in previous steps (RamosMoreno et al. 2019).
The intravariability in the step width is represented by the lateral movement of the CoM of each pedestrian described by integrating Eqs. (9), (10), and (11) for every step.
For consecutive steps, if the velocity is not affected by external constraints (structural elements or other people defined in the crowd model), then the step frequency for the next step will be computed applying the MCMC methodology. Otherwise, if the pedestrian’s velocity is affected by other pedestrians or constraints, through the crowd model, the new pedestrian speed will be calculated, and the new pedestrian frequency will be determined through Eq. (4).
Serviceability criteria
The comfort criteria for the pedestrians crossing the structure is verified by comparing the structural vertical and lateral accelerations to the limits proposed by BSI (2003, 2008), ISO (2005), and the SETRA guidelines (Charles et al. 2006) (Fig. 4). If the dynamic response exceeds these limits, TMDs will be implemented to attenuate the structural accelerations under the limits, and therefore satisfying the serviceability limit state of vibrations.
Structural damping
Several studies have suggested appropriate values of the damping ratio, ξ, for footbridges under pedestrian loads. Tilly et al. (1984) showed that it is common to find footbridges having equivalent viscous damping ratios lower than 1% of critical damping based on tests conducted for several footbridges under pedestrian loading. The work of Bachmann and Weber (1995) showed minimum, maximum and mean damping ratios according to the structural materials of the footbridge. These damping ratios are normal for traffic loads under service conditions, but significantly smaller than those activated under other dynamic actions inducing larger demands in the structure, closer to ultimate limit state. Some researchers and guidelines suggested not to overestimate the structural damping. This is to ensure a conservative analysis of the dynamic analysis response to avoid underestimating the potential dynamic response. The minimum recommended values for the damping factors have been considered for the girder footbridges in this study. This has been strongly recommended by (Heinemeyer and Feldmann 2008; Van Nimmen et al. 2014). Therefore, the following values have been chosen (Table 4):
Damping devices
A variety of supplemental damping devices have been used in built footbridges to mitigate vertical and lateral vibrations (Caetano et al. 2010; Caetano and Cunha 2014; Meinhardt 2008). Among them, TMDs are the most frequent type, being reliable, efficient and having a relatively low cost (Schlaich et al. 2005; Low 2008). Out of a dataset compiled by the authors, made of 54 built footbridges with supplemental damping devices implemented to reduced humaninduced vibrations, TMDs were the most common type (used in 76% of the cases), followed by viscous dampers (13%) and TMD viscous dampers (4%). Single examples (2% of the cases) using other devices (such as semiactive TMD MR dampers, telescoping hydraulic dampers, frictional dampers, and tuned liquid dampers) were identified.
Many of the damping devices have been implemented after construction, when geometrical, structural, and aesthetic constraints significantly reduce the number of potential solutions that could have been considered during the design stage. However, damping devices also can be considered within the design stages, facilitating the design of slenderer, yet comfortable, footbridges. Nevertheless, the use of these devices at the design stage is still rare, and additional guidance, code prescriptions, and methodologies are required. Eurocode 1993–2 Part 2 (BSI 2009b) mentions that dampers can be employed to mitigate humaninduced vibrations, but it does not provide any design procedure or requirement.
Multiple researchers have proposed different procedures to determine the optimum parameters of TMDs (Table 5) for different scenarios: Soong and Dargush (1997) minimized displacements in undamped structures under harmonic excitations; Warburton (1982) and Krenk et al. (2005) minimized accelerations in undamped structures, with the former considering white noise; and Nishihara and Asami (2002) minimized the accelerations in structures with low damping ratios.
Design methodology
In order to determine the optimal criteria to define the TMDs parameters and locations, a comprehensive parametric study was conducted, considering different locations and mass ratios μ (with typical values in footbridges varying from 0.01 to 0.05  see Tubino and Piccardo (2015)). An important design objective is minimizing the mass of the TMD, and therefore its size and cost, finding the minimum mass ratio that is required to fulfil the serviceability criteria. It is well known that the position of the TMD has an impact on its efficiency (Nishihara and Asami 2002). The TMD efficiency β can be measured as the percentage of the peak acceleration (prior to the implementation of this device) that would be cancelled after its installation. The design constraints set limits on the relative displacement between the TMD and the deck, as well as the deck vertical and lateral accelerations. The numerical procedure adopted in each of the studies performed is as follows:

1.
The mass, stiffness and damping matrices of the pedestrian bridges are assembled.

2.
The structural modal frequencies and mode shapes are determined for the solution without TMDs. At this stage, potential critical modes of the footbridge under pedestrian loading can be initially identified as those with vertical frequencies in the range of the pedestrian vertical frequencies (see Table 3), and those with lateral and torsional frequencies in the range of the pedestrian lateral frequencies (half of the vertical pedestrian frequency) (GarciaTroncoso et al. 2017). These modes are likely to have large contributions (point 5 below).

3.
The structure is loaded considering the probabilistic pedestrian load model defined in Section 2.2. Different loading scenarios are considered, varying the traffic conditions (such as modelling the pedestrian behaviour at peak hours, called commuting, and also during the weekends and more relaxed situations, called leisure), for different pedestrian densities (0.2, 0.6, and 1.0 pedestrians/m^{2}).

4.
The vertical and lateral dynamic response induced by each pedestrian flow is calculated (Clough and Penzien 1993). Multiple simulations are run, with the number of simulations (10) determined through a sensitivity analysis.

5.
If the maximum structural accelerations obtained exceed the comfort limits, and therefore do not satisfy the serviceability criteria, TMDs are deployed. The frequency of the TMD is tuned to damp the accelerations induced by that critical mode. The efficiency β of this device depends on the ratio between the TMD and the structural modal masses (μ), the ratio between the TMD and the structural frequencies (α), the TMD damping ratio (ξ), and its location. The mass ratio is initially set to 0.01, being incremented, if necessary, when further analyses are required after point 7. The optimal values α_{opt} and ξ_{opt} given by Warburton (1982), Soong & Dargush (1997), Nishihara and Asami (2002), and Krenk et al. (2005) (see Table 5) have been used in order to select the most efficient TMD to improve the pedestrian comfort.

6.
The mass, stiffness and damping matrices are updated including the TMD’s properties.

7.
The new dynamic response, considering the damping devices, is obtained. Then, the serviceability criteria are checked. If the serviceability criteria are not fulfilled, step 5 is repeated, incrementing the damper mass ratio in an iterative way until the serviceability criteria is finally satisfied.
Numerical model and sensitivity analyses
A finite element model (developed in Python (VanRossum and Drake 2010), and verified against ABAQUS (2014)) has been developed to evaluate the vertical and lateral dynamic response of a comprehensive set of girder footbridges (Table 1), under several pedestrian flows, with different densities (0.2, 0.6, 1.0 ped/m^{2}) and aims of the pedestrian journeys (business, commuting or leisure activities), with individual pedestrians being sampled as representatives of the UK population. The simplysupported girder footbridges are represented by using 1dimensional beam elements located at the sectional centroid. Their length was determined through a sensitivity analysis, covering the range from L/2 to L/40, for a given span length (L). Results effectively converged to a solution from L/15 with smaller element lengths not influencing the results. The actions were applied on the deck surface and transferred to the beam element.
In order to define the duration of the numerical simulations, further sensitivity analyses were conducted. At the beginning of each simulation, the first pedestrians enter the footbridge, arriving with the desired pedestrian density. After a while, a steady state response is achieved, and the structure corresponds to a stationary ergodic process. This is when the statistical analysis of multiple different or longer single simulations leads to similar results. Simulations of different durations were analysed, ranging from two to nine times the time expected for an average pedestrian to cross the bridge (t_{ap}) with the duration measured from the instant when the desired pedestrian density had been already achieved on the structure.
The response converged for a duration of 3t_{ap}, and therefore this value was adopted to evaluate the dynamic response in all of these parametric studies.
The impact of assuming that pedestrians can arrive in one or two directions, and the effects of the crowd interaction model were also analysed (Fig. 5). Case 1 does not consider the interaction between pedestrians (i.e. two pedestrians could be at the same location at the same time, or very close to each other, in positions which are not physically possible) while cases 2 to 5 consider the crowd interaction. Figure 6 shows the root mean square (RMS) vertical accelerations for a 1 s interval (Camara and RuizTeran 2015) for 10 simulations in the five different cases that were considered in Fig. 5. RMS accelerations are calculated in function of the time acceleration (t), and t_{1} and t_{2} which is the time interval (Eq. 14).
Larger responses are achieved when the pedestrians enter the footbridge with a uniform distribution across the width (cases 1, 4 and 5). The impact of the direction followed by the crowd and therefore the difference between unidirectional (Case 4) and bidirectional traffic (Case 5) is negligible. For the rest of the analyses in this work, pedestrians arrive in both directions and the crowd model is implemented (Case 5).
Dynamic response in the vertical direction
Single tunedmass damper
As expected, the greatest TMD efficiency is achieved when the TMD is positioned at the location of the maximum nodal coordinates for the modal shape that dominates the response. At that location, the efficiency of the TMD increases and therefore a smaller mass ratio is required to fulfil the serviceability criteria. For the girders considered, the maximum reduction of the dynamic response is achieved when the tuned mass damper is located at midspan (Fig. 7). Nevertheless, very similar efficiencies are achieved when the TMD is located in the central 30% of the span (β is equal to 74.50%, 79.40%, and 80.65%, when a TMD is located at 0.35 L, 0.40 L, and 0.50 L respectively for the case considered in Fig. 7). This conclusion is important for design as it gives flexibility to the designers when locating the TMDs. Nevertheless, by shifting the TMD towards the support sections, there is no benefit in reducing the vibrations linked to a second mode, or modes with a zero nodal coordinate at midspan, as the TMD is not tuned to that modal frequency. Asami’s TMD design criteria led to more efficient TMDs, and therefore larger reductions in accelerations, in comparison to the other criteria. Asami’s criteria gives larger efficiencies because it was set to minimise the accelerations in structures with low damping, such as in footbridges, where the comfort criteria for these structures is governed by accelerations.
Figure 8 shows the maximum vertical accelerations at midspan for prestressed (section type 1) footbridges under pedestrian loading (leisure activities) with different span lengths. It is noticeable that for certain span lengths (close to 25 m) the serviceability criterion is not fulfilled when TMDs are not implemented, as the frequency of the structure matches the average pedestrian frequency, and a resonant effect is induced. In this case, a single TMD (μ = 0.04) was enough to mitigate the humaninduced vibrations. By implementing a TMD designed following Asami’s criteria, the accelerations were significantly reduced (β = 80%), down to the levels. In addition, the TMD also reduces the internal forces by mitigating the dynamic response (see Fig. 9). At resonance, when L = 25 m, the dynamic component of the bending moments at midspan is very large, with a dynamic amplification factor (DAF) of 3.27. Nevertheless, the implementation of a TMD reduces the total, and the dynamic bending moments by 31 and 44% respectively, reducing the DAFs to 2.27. Similar values have been observed for a 12.5 m span. In this case there is also a resonant effect, with every pedestrian step is resonant with every other vibrational modal cycle.
Multiple tunedmass dampers (MTMDs)
The same structural type and cross section considered in the previous subsection is analysed herein under commuter traffic. The main critical span is now 22.5 m, rather than 25 m, as a consequence of the increment of the pedestrian frequency (from leisure to commuting) producing resonant effects for higher fundamental structural frequencies, i.e., for smaller span lengths (See Fig. 10). The modal shape in Fig. 10b is denoted by V followed by a number which represents the vertical mode with Nhalf waves.
One tuned mass damper with a larger mass ratio (μ = 0.05) located at midspan is now required to mitigate the humaninduced vibrations under the comfort limits when L = 22.5 m (Fig. 11a). The increment in the mass ratio is due to the increment of the vertical forces (which are frequency related, see Table 3, as well as the small structural mass, leading to larger accelerations as a consequence of Newton’s second law. Larger increment of TMD’s mass ratios only leads an 8% reduction in accelerations.
As expected, the serviceability criteria can be fulfilled with a single TMD located at midspan for bridges up to 50 m long (Fig. 11b). However, for larger spans of 80 and 100 m, two and four TMDs, respectively, are required at midspan, leading to total masses in the supplemental damping devices equal to 10% and 20% of the structural mass. For larger spans, both the structural mass and the total mass increase, leading to the requirement of significantly larger TMDs (see Table 6). For span lengths longer than 100 (m), the Mode Vertical 2 (V2) become more relevant (Fig. 10b). Therefore, it is required to check in the mode that has a larger contribution in a frequency domain analysis in order to evaluate the optimum location of the TMDs.
In some cases, the geometrical constraints may lead to splitting the TMDs into two during a more detailed stage of the design. When a single TMD is split into two (halving the mass m, the stiffness k and the damping c, and maintaining the TMD frequency and damping ratio) shifting them longitudinally at both sides of the midspan, the efficiency of the TMD system is barely affected, as long as they are both still located with the central 30% of the span length (i.e., ±15% span from the midspan). For instance, when L = 22.5 m, the maximum peak accelerations at midspan drop from 1.886 to 0.389 m/s^{2} introducing one TMD (μ = 0.05) at midspan, and to 0.411 m/s^{2} when two TMDs (μ = 0.025 each) are located at ±3 m from midspan. This is consistent with the results shown in Fig. 7a. Figure 11b shows that for spans longer than 50 m, the accelerations increase dramatically without supplemental damping devices. Therefore, the number of TMDs that are required to satisfy the comfort limits also increase significantly. Nevertheless, given the size (Table 6) and number of TMDs (Fig. 11b), it is possible to locate all the TMDs required within that central section (i.e., ±15% span from the midspan) guaranteeing a large efficiency of the TMD system (β = 80%) and the verification of the serviceability criterion.
Cost analysis
RamosMoreno et al. (2019) demonstrated that increasing the slab thickness (i.e., adding mass) was the most efficient way of controlling accelerations with the structural parameters (i.e., without implementing supplemental damping devices) in these types of footbridges. By adding mass, the accelerations are reduced, although this effect could be counteracted by the frequency shift if the structural frequencies get closer to the load frequencies. However, adding mass also increases the structural demands due to selfweight and seismic response, leading to increasing the capacity of several structural members. A comparative cost study between these two design alternatives (implementing TMDs or increasing the slab thickness) is included herein. The unit costs considered are shown in (Table 7) are those from (Bourne 2013) updated by 7.3% to reflect the cumulative effects of inflation since the publication of these costs. The TMD considered has a mass of 250 kg, a tuning range from 1.4 to 2.8 Hz, a damping ratio from 10 to 15%, and a maximum displacement range of ±40 mm, whose unit cost has been provided by a worldwide supplier. Other costs are not considered herein, as the aim is comparing the relative deck material cost for both design alternatives.
The TMD would probably need to be replaced during the footbridge service life. Technical brochures of TMDs highlight that their lifetime is around 20 years (leading to 4 replacements in 100 years). However, this seems very conservative based on recent publications. Weber and Feltrin (2010) and Meinhdart et al. (2017), stated that after 16 years of setup, TMDs still showed a satisfactory performance. The TMDs installed in a footbridge at Frottmanin Subway Station, in Munich, were still working properly 21 years after, and have only required very little maintenance (cleaning and refilling the oil of the damper pot) (Benicke 2017). Therefore, Maurer now recommends one replacement in 100 years, including two maintenance sessions (Benicke 2017). This uncertainty in the number of TMD replacements has been considered in this study, through different TMD life lengths (20, 25, 33.3, 50 and 100 years). The same unit cost has been considered for those replacements of TMDs in future years, assuming that the investment (discount) and inflation rates would be similar, as the proper consideration of these additional uncertainties are beyond the scope of this analysis.
The cost analysis (see Fig. 12) has been performed for a prestressed concrete (section type 1) footbridge with an 11.25 m span length, for different deck depths, considering the design scenario of pedestrian densities of 0.6 ped/m^{2} (commuters). A deck depth of L/24 is required to fulfil the serviceability criterion (peak acceleration ≤ 0.7 m/s^{2}) without TMDs, leading to a material cost for the deck of 14,091 GBP. From L/25 to L/35 the solutions with supplemental damping would require the installation of a single TMD at midspan. Two TMDs would be required for the range from L/39 to L/43, and four TMDs for L/49. When TMDs are being used, regardless of the TMD expected life, the smallest material cost is achieved for deck depths of L/35. If the TMD expected life can be assumed equal to 100 years, as recommended by (Benicke 2017), then the design with TMDs and deck depth of L/35 would lead to the most economical solution (12% cheaper than that for L/24 without TMDs), and very small increments would occur for deck depths down to L/43. For shorter expected lives of the TMDs of 50, 33.3, 25 and 20 years, the solutions with TMDs and deck depth of L/35 would be 2%, 16%, 35% and 45% more expensive (for the deck materials) than that for L/24 without TMDs. Nevertheless, there would be additional savings in other structural members such as bearings, abutments and foundations. For deck depths thinner than L/43 the deck material cost increases significantly.
Cross section types
A comprehensive parametric analysis was undertaken considering all the others section types in Table 1 for different span lengths. Figure 13 shows the structural frequencies for the different section types. It is noticeable that for certain span lengths and materials, the serviceability criterion is not fulfill when TMDs are not employed, showing resonance effects (see peaks in Fig. 14). Therefore, one to four TMDs were located at the maximum nodal displacement of the modal shapes, i.e., at midspan, to analyse the effect of the reduction of the dynamic response. Furthermore, for longer span lengths, the Mode Vertical 2 (V2) become more relevant.
Table 8 shows the TMD properties (minimum mass of the TMD) that can be employed for each of the resonant cases, activated at particular span lengths. For cross section types 1 to 8, it is sufficient to employ one tunedmass damper to satisfy the serviceability criteria. In addition, when a larger number of TMDs is used, there is not a significant reduction of the accelerations. However, for cross sections types 9 and 10, one to four TMDs are not sufficient to control the humaninduced vibrations. In these ultralight cross sections, the serviceability limit state is not fulfilled even when a large number of TMDs are used.
Dynamic response in the lateral direction
The lateral peak accelerations increase almost linearly with the span length (see Fig. 15). For given deck widths, these footbridges will have lateral vibration problems above a certain span length. For deck widths equal to L/20, the limit accelerations are exceeded from span lengths of 20 m. Nevertheless, if the deck width is doubled up to L/10, the serviceability criteria are fulfilled for span lengths from 20 to 100 m. Supplemental damping devices are required for cases in which the deck width is equal to L/20 to mitigate the lateral humaninduced vibrations (Fig. 16 and Table 9). The maximum lateral peak accelerations when one lateral TMD is employed are similar to those when the deck width is doubled and no supplemental damping is used (Fig. 16). Furthermore, if the span length is increased beyond 100 m, the comfort limits will not be satisfied, and lockin effects will become relevant.
Conclusions
A very comprehensive range of girder footbridges with different section types, materials, and geometrical configurations (deck depths, widths, and span lengths) were considered to understand their structural response under different pedestrian flows, as well as the benefits in implementing tuned mass dampers (TMD). The conclusions of this research work have been drawn through complex numerical analyses, implementing a realistic description of the pedestrian loading through a stochastic model including pedestrian intra and intersubject variability, pedestrianpedestrian interaction (crowd flow) and pedestrianstructure interaction.
The main original conclusions of this study are as follows:

The greatest efficiency of the TMDs is achieved when the TMD characteristics are determined using Asami’s formulations, given the low damping in footbridges and the fact that the comfort criterion is governed by accelerations.

The larger efficiencies of the TMDs are achieved when they are located at the maximum nodal coordinates of those modal shapes dominating the response. Nevertheless, provided the TMD location remains with the central 30% of the span length, the high values of the efficiencies, reducing the vertical peak accelerations by up to 80%, are not affected. The implementation of TMDs also reduces the dynamic component of the internal forces, to a lesser extent than for the accelerations.

For vertical accelerations, the serviceability criteria can be fulfilled with a single TMD, with a 0.05 mass ratio, located at midspan for bridges up to 60 m long. However, for larger spans of 80 and 100 m, two and four TMDs, respectively, are required at midspan, leading to total masses in the supplemental damping devices equal to 10% and 20% of the structural mass. Large TMDs can be split into two, provided both remain located in the central 30% of the span length, with variations of the efficiency of 1%.

For vertical accelerations, the most costeffective solution is achieved for deck span ratios of 1/35 when TMDs are used. If the TMD does not need to be replaced, or is replaced only once, throughout the service life, the deck material cost would be smaller, or similar, to the case without TMDs and a deck span ratio of 1/24.

Vertical accelerations in ultralight footbridges, with cross sections made of aluminium or glass fibre reinforced polymers, and conventional deck span ratios (1/30 and 1/40), do not satisfy the comfort criterion even after implementing multiple TMDs. Therefore, the slenderness and the structural masses have to be governed by the dynamic response, losing the lightness achieved by implementing these materials. For these structures, the Serviceability Limit State of Vibrations is critical for the design.

For span lengths up to 100 m, TMDs are not required to control lateral accelerations when the width span ratios are larger than 1/10. However, TMDs are required for span lengths larger than 20 m when the width span ratios are equal or smaller than 1/20.
